• Home > GLASS FIBER > GLASS FIBER 품종별 종류

YARN DESCRIPTION	FILAMENT Dia.(㎛)	TEX (g/1000m)	TENSILE STRENGTH (N/Tex)
ECD 900 1/0 1 Z	5	5.6	> 0.39이상 >0.34이상
ECD 450 1/0 1 Z	5	11.2
ECD 450 1/2 4.4S	5	22.5
ECE 225 1/0 1 Z	7	22.5
ECG 150 1/0 0.7Z	9	33.7
ECG 150 1/2 3.8S	9	67.5
ECG 150 1/3 3.8S	9	101.2
ECG 75 1/0 0.7Z	9	67.5
ECG 75 1/2 3.8S	9	135.0
ECG 75 1/3 3.8S	9	202.5
ECG 75 1/4 3.8S	9	270.0
ECG 75 2/2 2.5S	9	270.0
ECH 55 1/0 0.7Z	11	92.0
ECH 55 1/2 3.8S	11	184.0
ECH 55 1/4 3.8S	11	368.0
ECH 50 1/0 0.7Z	11	101.2
ECE 50 1/3 3.8S	11	303.7
ECH 50 1/4 3.8S	11	404.8
ECH 50 2/3 3.8S	11	607.2
ECH 50 2/4 3.8S	11	809.6
ECH 45 1/0 0.7Z	11	112.5
ECH 45 1/3 3.8S	11	337.5
ECH 45 1/4 3.8S	11	450.0
ECH 45 2/3 3.8S	11	675.0
ECG 37 1/0 0.7Z	11	136.8
ECG 37 1/3 3.8S	11	410.4
ECH 25 1/0 0.7Z	11	202.4
ECK 18 1/0 0.7Z	13	281.2
