GLASS FIBER 직물 • Home > GLASS FIBER > GLASS FIBER 직물





DESCRIP-TION YARN COUNT(YARN/IN.) WEAVE WEIGHT(g/m²) WIDTH(mm) THICKNESS(mm)
WARP FILL WARP FILL
1080 D450 1/0 D450 1/0 61 48 PLAIN 49 1020 0.05
108 E225 1/0 E225 1/0 44 33 PLAIN 76 1020 0.08
110 E225 1/0 E225 1/0 60 57 PLAIN 105 1020 0.1
G118 G75 1/0 G75 1/0 34 34 PLAIN 183 1020 0.18
K126 G37 1/0 G37 1/0 30 20 PLAIN 273 1020 0.26
K132 G37 1/0 G37 1/0 34 22 PLAIN 306 1020 0.32
HG181 DE 75 1/0 G75 1/0X2 57 54 8-H SATIN 293 1020 0.25
HG1581 G150 1/2 G150 1/2 57 54 8-H SATIN 293 970 0.25
210 G150 1/0 E225 1/0 64 25 4-H SATIN 108 1020 0.1
G218 G75 1/0 G150 1/0 64 26 4-H SATIN 207 1020 0.18
220 G75 1/0 G150 1/0 58 35 4-H SATIN 109 1020 0.1
K224 G37 1/0 G150 1/0 50 26 4-H SATIN 305 1020 0.24
310 G150 1/0 X 2 G75 1/0 10 10 LENO PLAIN 54 1020 0.1
R362 G37 1/0 X 2 ER 270 6.2 6.2 LENO PLAIN 135 1030 0.26
R366 H25 1/0 X 2 ER 390 6.2 5.8 LENO PLAIN 191 1320 0.33
R385 H50 1/3 X 2 H45 1/3 8 8 PLAIN 216 1120 0.35
381 G150 1/0 X 2 G75 1/0 8 8 LENO PLAIN 43 1020 0.1
